Vitap | Blitz 3.0
CNC DRILLING GLUING AND DOWEL INSERTING MACHINE
The ideal solution for those who need large production or “Just in Time” work
Blitz is a drilling gluing and dowel inserting machine with numerical control. Efficient and reliable, it is extremely intuitive to use thanks to the simplicity of its dedicated software. Equipped with 3 horizontal drilling heads and 3 vertical, it is the ideal solution for both high-scale and on-demand production.
Blitz is a numerically controlled machine that is able to perform the boring and insertion of the pins in an extremely precise way. The TPA software allows quick and easy programming, while the automatic injector cleaning device and the fast injector release make maintenance even easier.
Blitz is also the necessary complement for horizontal boring execution in the nesting philosophy.
Highlights
- Speed in processing (6000 rpm)
- Ideal for large quantities
- Easy and intuitive programming
SPECIFICATIONS:
• Welded steel frame
• Manual load and unload
• 3 axis control
• TPA Albatros software
• 3 drilling spindles horizontal
• 3 drilling spindles vertical
• High capacity dowel feeder
ELECTRICAL DATA:
• 230 V – 3 Ph – 60 Hz, 10 amps
CNC DRILLING GLUING DOWEL INSERTING
• Blitz CNC drilling gluing and dowel inserting machine
(axis X) 1300mm.
• 3 Controlled axes (X , Y, Z)
• Highly efficient and reliable thanks to easy to use
software.
• Ideal for "JUST IN TIME" production or mass
production.
• Blitz, the necessary complement for horizontal and
vertical drillings execution in "NESTING" philosophy.
MACHINE STANDARD EQUIPMENT
• 3 horizontal independent spindles
• 3 vertical independent spindles
• glue and dowel inserting unit
• high capacity vibrator to feed the dowels
• 2 working areas
• 2 sides reference stops (dx,sx) on the working table
• central reference stop on the working table 4 clamps
DRILLING HEAD:
• 3 independent horizontal spindles at 3500 speed /min.
• 3 independent vertical spindles at 3500 speed/min.
• WORKING AREA HORIZONTAL HEAD:
• X= 1300 mm
• Y= 50 mm
• Z= 50mm
INSERTING GLUE AND DOWEL UNIT:
• glue and dowel injector. Dowel dimension: min
6x25mm; Max 10x40mm
GLUE SYSTEM:
• glue pump
• Pressure glue system pump.
• water tank "for cleaning"
HARDWARE AND SOFTWARE
• Monitor LCD TFT 19"
• PC windows system
• Albatros TPA software
