CANTEK | C371 36" Wide Belt Sander (60" Belt)

Original price $19,300.00 - Original price $19,300.00
Original price
$19,300.00
$19,300.00 - $19,300.00
Current price $19,300.00

Dependable, consistent sanding results with a robust design that is built to last.

The Cantek C371 36″ Widebelt Sander is compact and versatile with a combination sanding unit for calibration and final sanding. The robust sanding unit and heavy-duty frame ensures optimum sanding results. Motorized thickness adjustment with digital thickness control for fast and accurate table adjustment.

Why Cantek C371 36″ Widebelt Sander?

  • Accurate digital thickness control with both Inch & Metric settings allows operator to key in the desired thickness and table will automatically move into position.
  • Small footprint
  • Combination sanding unit with 5” rubber contact drum and 2” wide adjustable sanding platen for a wide range of sanding applications.

Key Advantages

  • Electronic belt tracking for optimum belt life and sanding results
  • Ammeter for load monitoring to ensure the proper amount of material is being removed according to the selected grit.
  • Disc brake on main motor allows for faster belt changes
  • Pneumatic belt tensioning with quick release outboard support to facilitate fast belt changes.
  • Double infeed and outfeed pressure rolls for superior part hold down
  • Four table raising jack screws
  • Material over-height limit switch
  • Hour meter records the actual running time of the machine which can be used to provide timely maintenance for the machine
  • Interlocks located on all access doors.
Specifications


Inch
Metric
Abrasive belt size
37” x 60”
939 x 1524 mm
Main motor
20 HP
Feed motor
2HP
Table rise/fall motor
½ HP
Maximum width stock
36”
910 mm
Minimum part length
13”
330 mm
Maximum thickness opening
5”
127 mm
Feed speed: variable
13 to 52 FPM
4 to 16 m/min
Passline height
33”- 38”
838 – 965 mm
Infeed table
11 ½”
292 mm
Dust outlet
1 @ 5”
1 @ 127 mm
Compressed air usage
2 CFM @ 90 PSI
2 CFM @ 90 PSI
New weight
1980 lbs
900 kgs
Machine dimensions
64” x 53” x 73”
1625 x 1346 x 1854 mm
Shipping weight
2530 lbs
1150 kgs
Shipping dimensions
67” x 55” x 78”
1701 x 1397 x 1981 mm
