161-BT35-ER32-126 : BT 35 x ER 32 - 126 with #46132 nut
by Techniks USA
Original price
$259.20
-
Original price
$259.20
Original price
$259.20
$259.20
-
$259.20
Current price
$259.20
Specifications
| Item Number | 161-BT35-ER32-126 |
|---|---|
| Item Description | BT35 Collet Chuck x ER32 - 126mm projection |
| Taper | BT35 |
| Body Dia | 35mm |
| Shank Size | 35mm |
| Weight | 3.3 |
| Collet series | ER32 |
| Taper length | 56.4mm |
| Nose dia | 50mm |
| Projection Length | 126mm |
Overview
**All images are representative images. Verify specifications before placing orders.** Techniks Tool Group Collet Chucks are designed to deliver excellent performance in a wide range of machining applications including milling,drilling,and tapping. Our exclusive PowerCOAT nuts come standard on all ER and TG Collet Chuck providing 75% more holding power on the tool shank vs. standard collet nuts for improved safety and reduce the potential of tool slippage. Both through-spindle and CoolFLEX AD+B flange coolant delivery are available. Balanced to 25,000 RPM at G2.5 Maximum 0.0001" T.I.R. measured from taper to collet pocket PowerCOAT Nut increases holding power by 75%
