23030 : CAT 50 x TG 100 - 3"
by Techniks USA
Original price
$184.50
-
Original price
$184.50
Original price
$184.50
$184.50
-
$184.50
Current price
$184.50
Specifications
| Item Number | 23030 |
|---|---|
| Item Description | CAT50 Collet Chuck x TG100 - 3" projection |
| Taper | CAT50 |
| Body Dia | 2.75" |
| Shank Size | 3.875" |
| Weight | 7.7 |
| Collet series | TG100 |
| Taper length | 4" |
| Nose dia | 3.88" |
| Projection Length | 3" |
Overview
**All images are representative images. Verify specifications before placing orders.** Techniks Tool Group Collet Chucks are designed to deliver excellent performance in a wide range of machining applications including milling,drilling,and tapping. Our exclusive PowerCOAT nuts come standard on all ER and TG Collet Chuck providing 75% more holding power on the tool shank vs. standard collet nuts for improved safety and reduce the potential of tool slippage. Both through-spindle and CoolFLEX AD+B flange coolant delivery are available. Balanced to 25,000 RPM at G2.5 Maximum 0.0001" T.I.R. measured from taper to collet pocket PowerCOAT Nut increases holding power by 75%
