23018F : CAT 40 x TG 100 - 6" with CoolFLEX
by Techniks USA
Original price
$191.70
-
Original price
$191.70
Original price
$191.70
$191.70
-
$191.70
Current price
$191.70
Specifications
| Item Number | 23018F |
|---|---|
| Item Description | CAT40 Collet Chuck x TG100 - 6" projection with CoolFLEX DIN-B coolant ports |
| Taper | CAT40 |
| Features | Coolflex |
| Body Dia | 1.75" |
| Shank Size | 2.5" |
| Weight | 4.8 |
| Collet series | TG100 |
| Taper length | 2.69" |
| Nose dia | 2.5" |
| Projection Length | 6" |
Overview
**All images are representative images. Verify specifications before placing orders.** Techniks Tool Group Collet Chucks are designed to deliver excellent performance in a wide range of machining applications including milling,drilling,and tapping. Our exclusive PowerCOAT nuts come standard on all ER and TG Collet Chuck providing 75% more holding power on the tool shank vs. standard collet nuts for improved safety and reduce the potential of tool slippage. Both through-spindle and CoolFLEX AD+B flange coolant delivery are available. Balanced to 25,000 RPM at G2.5 Maximum 0.0001" T.I.R. measured from taper to collet pocket PowerCOAT Nut increases holding power by 75%
