141.122.16.070 : Capto C4 x ER 16 - 70
Specifications
| Item Number | 141.122.16.070 |
|---|---|
| Item Description | PSC4 Collet Chuck x ER16 - 70mm projection |
| Taper | PSC4 |
| Body Dia | 40mm |
| Shank Size | 28mm |
| Wrench | 04609 |
| Weight | 0.9 |
| Collet series | ER16 |
| Taper length | 24mm |
| Nose dia | 28mm |
| Projection Length | 70mm |
Overview
**All images are representative images. Verify specifications before placing orders.** Techniks offers a wide selection of tool holder types for multi-tasking mill-turn machines that have Capto® spindles. Techniks PSC holders are certified for perfect fit with spindles based on the DIN 26623-1 standard. Popular sizes of C4,C5,and C6 are available in ER collet chucks,end mill holders,shrink fit holders,SlimFIT holders,face mill arbors,and right and left-handed turning tools. Techniks PSC holders are a perfect choice when using popular mill-turn machines such as Mazak Integrex,Okuma Multus,Doosan Puma MX and SMX,and DMG Mori CTX TC,NT,and NTX series machines. Balanced to 25,000 RPM at G2.5 Maximum T.I.R. 0.0001" measured from taper to collet pocket PowerCOAT Nut included and increases holding power by 75% Capto Compatible
