12040-CMS : (CMS) ISO 30 x ER 40 - 66, with
by Techniks USA
Original price
$415.80
-
Original price
$415.80
Original price
$415.80
$415.80
-
$415.80
Current price
$415.80
Specifications
| Item Number | 12040-CMS |
|---|---|
| Item Description | ISO30 Collet Chuck x ER40 - 51mm projection |
| Taper | ISO30 |
| Body Dia | 46mm |
| Shank Size | 46mm |
| Wrench | 04617 |
| Weight | 2 |
| Collet series | ER40 |
| Taper length | 47.8mm |
| Nose dia | 40mm |
| Flats | 42mm |
| Projection Length | 51mm |
Overview
**All images are representative images. Verify specifications before placing orders.** Techniks Tool Group Collet Chucks are designed to deliver excellent performance in a wide range of machining applications including milling,drilling,and tapping. Our exclusive PowerCOAT nuts come standard on all ER and TG Collet Chuck providing 75% more holding power on the tool shank vs. standard collet nuts for improved safety and reduce the potential of tool slippage. Both through-spindle and CoolFLEX AD+B flange coolant delivery are available. Balanced to 25,000 RPM at G2.5 Maximum 0.0001" T.I.R. measured from taper to collet pocket PowerCOAT Nut increases holding power by 75%
