05178 : DE23 x ER16M - 60
by Techniks USA
Original price
$203.40
-
Original price
$203.40
Original price
$203.40
$203.40
-
$203.40
Current price
$203.40
Specifications
| Item Number | 05178 |
|---|---|
| Item Description | Double Ended Collet Chuck 23mm x ER16 - 26.6mm projection |
| Taper | DE23 |
| Body Dia | 23mm |
| Shank Size | 23mm |
| Weight | 0.4 |
| Collet series | ER16 |
| Taper length | 60mm |
| Nose dia | 22mm |
| Projection Length | 26.6mm |
Overview
**All images are representative images. Verify specifications before placing orders.** Techniks Tool Group Collet Chucks are designed to deliver excellent performance in a wide range of machining applications including milling,drilling,and tapping. Our exclusive PowerCOAT nuts come standard on all ER and TG Collet Chuck providing 75% more holding power on the tool shank vs. standard collet nuts for improved safety and reduce the potential of tool slippage. Both through-spindle and CoolFLEX AD+B flange coolant delivery are available. Balanced to 25,000 RPM at G2.5 Maximum 0.0001" T.I.R. measured from taper to collet pocket PowerCOAT Nut increases holding power by 75%
