05157 : DE20 x ER11M - 75
by Techniks USA
Original price
$183.60
-
Original price
$183.60
Original price
$183.60
$183.60
-
$183.60
Current price
$183.60
Specifications
| Item Number | 05157 |
|---|---|
| Item Description | Double Ended Collet Chuck 20mm x ER11 - 16.6mm projection |
| Taper | DE20 |
| Body Dia | 20mm |
| Shank Size | 20mm |
| Weight | 0.3 |
| Collet series | ER11 |
| Taper length | 75mm |
| Nose dia | 20mm |
| Projection Length | 16.6mm |
Overview
**All images are representative images. Verify specifications before placing orders.** Techniks Tool Group Collet Chucks are designed to deliver excellent performance in a wide range of machining applications including milling,drilling,and tapping. Our exclusive PowerCOAT nuts come standard on all ER and TG Collet Chuck providing 75% more holding power on the tool shank vs. standard collet nuts for improved safety and reduce the potential of tool slippage. Both through-spindle and CoolFLEX AD+B flange coolant delivery are available. Balanced to 25,000 RPM at G2.5 Maximum 0.0001" T.I.R. measured from taper to collet pocket PowerCOAT Nut increases holding power by 75%
