04851 : C16 x ER 11A - 140
by Techniks USA
Original price
$149.40
-
Original price
$149.40
Original price
$149.40
$149.40
-
$149.40
Current price
$149.40
Specifications
| Item Number | 04851 |
|---|---|
| Item Description | 16mm Straight Shank Extension x ER11 - 140mm projection |
| Taper | C16 |
| Body Dia | 16mm |
| Shank Size | 16mm |
| Weight | 0.5 |
| Collet series | ER11 |
| Taper length | 16.6mm |
| Nose dia | 19mm |
| Thread | M8x1 |
| Projection Length | 140mm |
Overview
**All images are representative images. Verify specifications before placing orders.** Techniks Tool Group Collet Chucks are designed to deliver excellent performance in a wide range of machining applications including milling,drilling,and tapping. Our exclusive PowerCOAT nuts come standard on all ER and TG Collet Chuck providing 75% more holding power on the tool shank vs. standard collet nuts for improved safety and reduce the potential of tool slippage. Collet pocket T.I.R. 0.0001"
