04834 : 3/4 x ER 16A - 50
by Techniks USA
Original price
$138.60
-
Original price
$138.60
Original price
$138.60
$138.60
-
$138.60
Current price
$138.60
Specifications
| Item Number | 04834 |
|---|---|
| Item Description | .75" Straight Shank Extension x ER16 - 50mm projection |
| Taper | STRSHK |
| Body Dia | 3/4" |
| Shank Size | .75" |
| Weight | 0.4 |
| Collet series | ER16 |
| Taper length | 24.5mm |
| Nose dia | 28mm |
| Thread | M22x1.5 |
| Projection Length | 50mm |
Overview
**All images are representative images. Verify specifications before placing orders.** Techniks Tool Group Collet Chucks are designed to deliver excellent performance in a wide range of machining applications including milling,drilling,and tapping. Our exclusive PowerCOAT nuts come standard on all ER and TG Collet Chuck providing 75% more holding power on the tool shank vs. standard collet nuts for improved safety and reduce the potential of tool slippage. Collet pocket T.I.R. 0.0001"
