Felder | K 500 professional Sliding Panel Table Saw
K 500 - the “small” Panel Saw from FELDER
Do not be fooled by the inconspicuous exterior of the FELDER K 500. The sliding table saw is a true power pack, despite its size.
With the innovative, tilting saw blade unit and precision double guiding for precise angle and height adjustment, the K500 guarantees a new dimension of efficiency. At the heart of the FELDER K 500, the powerful circular saw unit a circular saw shaft, which allows a saw blade with up to Ø 315 mm.
A ten year guarantee on the "X-Roll" sliding table, highest manufacturing quality and strict FELDER production standards make this sliding table panel saw reliable partner for many years to come.
Key Features
Highlights
- Powerful Cutting Capacity: Features a robust circular saw unit with a maximum cutting height of 102 mm using a 315 mm saw blade, delivering impressive performance in a compact design, enhanced by optional dado tooling.
- “X-Roll” Sliding Table with Durability: Offers a dust-proof, maintenance-free sliding table with a 10-year FELDER factory warranty, ensuring long-lasting precision and reliability.
- Professional Outrigger Support: Includes a solid 1100 mm outrigger table with a 2600 mm telescopic crosscut fence, supported by four rollers, providing stability and precision for large, heavy workpieces.
Details
- Cutting Specifications: Provides a 102 mm cutting height with a 315 mm saw blade (exact 45° height not specified, typically around 70–80 mm), with a standard sliding table length of 80⁴⁵/₆₄" (2050 mm), expandable to 98²⁷/₆₄" (2500 mm), and a rip capacity of 31½" (800 mm), optionally 49" (1250 mm).
Equipped with a 30 mm electronically balanced saw arbor powered by a Poly-V belt for near 100% power transmission, offering increased stability and safety, especially with dado tooling. Features an optional mechanical or electronic scoring unit with an 80 mm diameter, compatible with a 250 mm main saw blade, ensuring tear-free cuts in sensitive materials. Features a 2600 mm telescopic crosscut fence with a magnifying lens and miter scale, adjustable from 90° to 45°, with a fixed 90° end stop, supported by a solid outrigger table. Features a swing-away design for flexibility and safety, optimizing dust extraction and providing unrestricted access to the working area when equipped. Offers a standard 31½" (800 mm) rip capacity, upgradable to 49" (1250 mm) with a single-handed adjustment system and optional micro-adjustment, ensuring quick and accurate settings. Includes optional pneumatic workpiece holders (95 mm height, 300 kg force), a precision mitre guide index system, and table extensions. Web context suggests compatibility with additional safety or digital upgrades. Built with high-quality cast iron tables and aggregates, the K 500 professional ensures reliability, supported by Felder’s 60 years of experience and a comprehensive service package.
Technical Specifications
| Category | Details |
|---|---|
| Sawing Unit |
|
| General |
|
Specifications
What type of woodworking shop is the Felder K 500 designed for?
The Felder K 500 Professional Sliding Panel Table Saw is engineered for professional woodworking shops, custom cabinet manufacturers, and production facilities that need a versatile, robust panel saw for accurate panel sizing and solid wood cutting.
What materials can the K 500 cut?
The K 500 can accurately cut plywood, MDF, particleboard, laminated panels, solid wood, plastics, and other sheet materials when equipped with the proper tooling and blade selection.
What is the maximum cutting height of the K 500?
The K 500 offers a cutting height suitable for most cabinetry and furniture applications; exact capacity depends on blade size and configuration.
What blade sizes does the K 500 support?
The sliding saw supports a range of industrial blade diameters appropriate for panel cutting and solid wood processing based on material thickness and cutting needs.
How accurate is the sliding table on the K 500?
The Felder sliding table system uses precision-ground guideways and hardened steel rollers to deliver smooth movement and high repeatability for accurate panel sizing.
What control and adjustment features are included?
The K 500 includes digital readouts and precise manual or motorized adjustments (depending on configuration) for fence position, blade height, and angle to support accurate and repeatable cuts.
How does the K 500 handle angled and bevel cuts?
The saw unit tilts to allow bevel and angled cuts, with precise positioning available through the adjustment mechanisms on the machine.
Is the K 500 suitable for continuous production use?
Yes, the Felder K 500 is built with industrial-grade components and construction that support continuous use in demanding professional environments.
What safety features are included on the K 500?
The machine includes blade guards, riving knives, emergency stops, and provisions for dust extraction to improve operator safety.
What dust extraction requirements does the K 500 have?
Proper dust extraction should be connected to the saw and sliding table area to capture sawdust and chips at the source; a centralized or dedicated dust collector is recommended.
What motor power options are available for the K 500?
The K 500 is available with industrial motor options sized to match cutting requirements and local electrical standards.
How does the K 500 compare to smaller sliding table saws?
Compared to smaller sliding table saws, the K 500 offers a larger cutting capacity, heavier construction, and more precise adjustments for production-level panel processing.
Is the Felder K 500 manufactured in Europe?
Yes, the Felder K 500 Professional Sliding Panel Table Saw is engineered and manufactured in Austria to European precision standards.
Who should choose the Felder K 500?
The K 500 is ideal for professional shops that need a high-performance, reliable sliding panel saw with precision control and repeatability for panel sizing and solid wood cutting.
How does the K 500 fit into a production workflow?
The Felder K 500 integrates smoothly into production workflows by providing accurate cutting, fast setup adjustments, and solid support for multiple panel sizes and thicknesses.
