Felder | KF 500 professional Saw/Shaper

Felder | KF 500 professional Saw/Shaper

by Felder Group
$50,000.00 - $50,000.00
$50,000.00
$50,000.00 - $50,000.00
$50,000.00

Reliability, Durability, and Excellent Results

The Felder KF 500 professional Saw-Spindle Shaper offers an 80 45/64" cutting length and a 31 1/2" to 49 7/32" rip capacity, combining a robust panel saw and spindle moulder for professional woodworking with solid wood and panel materials. With a 43 5/16" outrigger table, X-Roll sliding table, and optional MF spindle system, it delivers precision and stability for industrial applications.

Key Features

Highlights

  • X-Roll Precision Guiding System: High-quality format sliding table with 10-year warranty ensures smooth, maintenance-free operation.
  • MF Spindle Shaft Quick Change System: Allows rapid spindle swaps of varying diameters without losing settings (optional).
  • MULTI-Fine Adjustment System: Enables quick, parallel fence adjustments with automatic repeat settings for spindle fence "230" (standard).

Details

  • Scoring Unit: Optional mechanically driven unit (Ø 80 mm) ensures chip-free cuts in laminated panels.
  • Felder Saw Unit “500”: Stable unit with 4 1/64" cutting height at 12 13/32" blade diameter, double-sided support, and smooth 0°–45° tilting.
  • Grooving Work: Optional dado tooling for adjustable grooves up to 19.5 mm wide.
  • Precision Mitre Index System: Enables accurate angle adjustments for efficient operation.
  • Pneumatic Workpiece Holder: Offers flexible clamping with 3 47/64" height and 661 lbs force, compatible with all sliding tables.
  • EGL 1350: Patented double cut mitre gauge for precise angle cuts with integrated computer, adjustable up to 53 5/32".
  • Crosscut Fence: 102 23/64" fence for +45° to –45° mitre cuts with precise stops.
  • Rip Fence: Adjustable 31 1/2" to 49 7/32" with single-hand clamping and fine adjustment.
  • Outrigger Table: Standard 1,100 mm table for processing large workpieces with precision.
  • Spindle Fence “230”: Supports tools up to 9 1/16" diameter, with –5 to +25 mm fine adjustment and 120 mm extraction connection.
  • Spindle Shaper Unit “500”: 3 15/16" usable height, four speeds (3,000/6,000/8,000/10,000 rpm), and 0°–45° rearward tilt for safety.
  • Power Feeder: Ensures clean, precise moulding for standard operations.
  • Tilt Bracket: Power feeder tilt-away device for convenient access.

Technical Specifications

Category Details
Electrics
  • 3x 400 V motor voltage (standard), 3x 230 V or 1x 230 V, 4.0 HP (3.0 kW) (optional)
  • 50 Hz (standard) or 60 Hz motor frequency (optional)
  • Motor power: 4.0 HP (3.0 kW, standard), 5.5 HP (4.0 kW, optional)
  • Switch for forward and reverse run (standard)
  • Optional additional emergency stop
Saw and Scoring Unit
  • Saw blade tiltable: 90°–45°, max. cutting height 4 1/64" with Ø 12 13/32"
  • Cutting width: 31 1/2" (standard), optional 49 7/32" or 31 1/2" with full table length
  • Optional dado capability: up to ¾" (19.5 mm) width
  • Optional mechanically driven scoring unit: Ø 80 mm with main saw blade Ø 9 27/32"
  • EURO II standard saw guard (standard)
  • Optional fine adjustment of rip fence
Spindle Shaper Unit and Spindle Fence
  • Shaper spindle: Ø 30 mm, 3 15/16" usable height (standard)
  • Optional MF spindle system: Ø 30 mm, 32 mm, 35 mm, 1¼", 50 mm, or collet chuck, 3 15/16" usable height
  • Spindle shaper fence 230 for max. tool Ø 9 1/16", 15 3/4" fence plates (standard)
  • MULTI-fine adjustment system for spindle shaper fence “230” (standard)
  • Anodised aluminium fence plates (standard)
  • Optional anodised aluminium fence plates with safety bar guides
  • Spindle shaper tiltable: 90°–45° with scale display, speeds 3,000/6,000/8,000/10,000 rpm
  • EURO spindle shaper guard (standard)
  • Table opening: 180 mm
Format Sliding Table, Slot and Tenoning Table
  • Format sliding table M: 80 45/64" cutting length (standard)
  • Anodised sliding table (standard)
Outrigger Table and Longitudinal Stops
  • 1,100 mm outrigger table (standard)
  • Optional 1,300 mm outrigger table
  • Optional 1,300 mm crosscut fence for all sliding table lengths
  • Optional telescopic extension for crosscut fence: 39 3/8" to 80 45/64"
  • Outrigger table crosscut fence: 102 23/64" (standard)
  • Optional precision mitre guide INDEX system
General
  • Extraction connection: 120 mm (spindle fence), 120/50 mm (saw unit/guard)
  • Working height: 890 mm
  • Weight: 480 kg (standard configuration)
  • Min. transport width: 800 mm
Accessories
  • Optional rolling carriage
  • Optional power feeder tilt-away device
  • Optional IPPC palette
  • Optional container transport preparation
